Renowned worldwide for their handling, accuracy and durability, each HEYM rifle made in Germany represents over 150-years of experience combined with the best in modern materials, machining capabilities and craftsmanship.
The SR30 action is extremely versatile as the rifle can be carried with the bolt closed but in the de-tensioned position and when ready to fire simply push the bolt handle forward. The mechanical bolt mounted safety only works in the detensioned position, which also locks the bolt handle in place to avoid accidental cocking of the bolt. This is the absolute definition of safety when it comes to a rifle.
The HEYM SR 30 locks up with 6 balls which are pushed out from the bolt into a channel. The biggest test was preformed in Beschussamt Suhl Germany where they successfully tested the SR30 lock up with 8000 loaded bar of pressure.
- straight pull bolt
- Krupp Steel, hammer forged barrel, made In-House at HEYM
- exceptional accuracy
- elegant design
- steel receiver
- detachable steel magazine, large capacity available
Barrel length:
Standard calibre & magnum calibre 60 cm
Total length:
Standard calibre & magnum calibre 110 cm
Weight:
3.6 kg
Stock:
Straight stock with German cheek, luxury grade 5 walnut, red rubber butt cap ( 20 mm ). Forend with ebony wood end, pistol grip with steel cap, fine checkering hand round cut, super fine finish with closed pores on wood surface.
Barrel:
Barrel Silhouette Keglisch " English Styling ". Muzzle 16 mm, with ring front sight, ring sling swivel and ring rear sight saddle.
Sights:
Express sights with one extra flip up blade rear sight and brass front sight
Available Calibres
SR 21 & SR 30
Medium Calibre
.22-250 Rem. / .25-06 / .243 Win. / 6,5 x 55 SM / 6,5 x 64 / .270 Win. / 7 x 57 / 7 x 64 / .308 Win. / .30-06 / .30-06 Ackley Improved (A.I.) / 8 x 57 JS / 8 x 64 S / 8,5 x 63 / 9,3 x 62
Magnum Calibre
6,5 x 68 / .270 WSM / .300 WSM / 7 mm Rem. Mag. / .300 Win. Mag. / .338 Win. Mag. / 8 x 68 S / .375 Ruger
Mini Calibre (Only right hand)
.222 Rem. / .223 Rem.
SR 21 / SR 30 COMPARISON CHART
| MODEL | CLASSIC | KEILER | PREMIUM | CONCORD | SUPER CLASSIC | ROYAL | GRAND ROYAL |
| RECEIVER MATERIAL | Steel | Steel | Steel | Steel | Steel | Steel | Steel |
| BOLT HANDLE BALL (Only optional for SR30) | SR21: Fixed steel SR30: Wood |
SR21: Fixed steel SR30: Wood |
SR21: Fixed steel SR30: Steel (Smooth) |
SR21: Fixed steel SR30: Wood |
SR21: Fixed steel SR30: Wood |
SR21: Fixed steel SR30: Steel checkered |
SR21: Fixed steel SR30: Steel checkered |
| RECEIVER SURFACE FINISH | Polish blued | Polish blued | Polish blued | Engraved & nitride hardened | Polish blued | Engraved & nitride hardened | Engraved & nitride hardened |
| BARREL SURFACE FINISH | Blued | Polish blued | Polish blued | Polish blued | Polish blued | Polish blued | Polish blued |
| OPEN SIGHTS, CLASSIC STYLE | Yes | Optional | Front sight with pearl inserted into brass cradle ring | Optional | Express style sights | Brass front sight and 1 rear sight leaf for 100 yds graduation | Optional |
| OPEN SIGHTS WITH ILLUMINATED INSERT | Optional | Yes | Optional | Yes | Optional | Yes | Yes |
| ENGRAVING | Optional | Optional | Optional | Yes | Optional | Yes (High Grade) | Yes (High Grade) |
| FLUTTED BARREL | Optional | Optional | Optional | Yes | Optional | Optional | Optional |
| FRONT SIGHT WITH BARREL BAND | Optional | Optional | Yes | Optional | Yes | Optional | Optional |
| REAR SIGHT WITH BARREL BAND | Optional | Optional | Optional | Optional | Yes | Optional | Optional |
| SLING ATTATCHMENT ON BARREL BAND | Optional | Optional | Yes | Optional | Yes | Optional | Optional |
| TRIGGER | 800g | 800g | 800g | 800g | 800g | 800g | 800g |
| TRIGGER BLADE | Black | Black | Black | Gold plated | Black | Gold plated | Gold plated |
| TRIGGER FRAME AND GUARD | Black anodized aluminium | Black anodized aluminium | Black anodized aluminium | Nitride hardened steel | Blued steel | Nitride hardened steel | Nitride hardened steel |
| MAGAZINE FLOOR PLATE MEDIUM CALIBRE | Blued steel | Blued steel | Blued steel | Nitride hardened steel with engraving | Blued steel | Nitride hardened steel with engraving | Nitride hardened steel with engraving |
| MAGAZINE FLOOR PLATE LARGE CALIBRE | Black anodized aluminium | Black anodized aluminium | Black anodized aluminium | Nitride hardened steel with engraving | Blued steel | Nitride hardened steel with engraving | Nitride hardened steel with engraving |
| STOCK STYLE CLASSIC OR HOGSBACK | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| SUFACE FINISH ON STOCK | Oiled | Oiled | Oiled | Gloss Oiled | Super finish with closed pores, high gloss oiled | Gloss Oiled | Super finish with closed pores, high gloss oiled |
| STOCK TIP WOOD FOR FOREND | Rosewood | Rosewood | Rosewood | Rosewood | Ebony hardwood | Rosewood | Ebony hardwood |
| BUTT PAD | 15mm black | 15mm black | 15mm black | 15mm black | 25mm red | 15mm black | 15 mm with leather cover |
| MAGAZINE CAPACITY | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| PISTOL GRIP CAP WITH HEYM LOGO | Yes | Yes | Yes | Yes | Steel grip cap | Yes | Skeleton steel grip cap |
| HEAVY BARREL PROFILE | Optional | Optional | 17mm Dia. | Optional | English styling 16mm Dia. | Optional | Optional |
| QUICK RELEASE SLING SWIVELS | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| WOOD GRADE | 3 | 3 | 3 | 4 | 5 | 4 | 7 |
| RIFLE LENGTH (M) MEDIUM CAL (G) MAGNUM CAL. | (M) 111cm (G) 114cm |
(M) 103cm (G) 111cm |
(M) 105cm (G) 111cm |
(M) 103cm (G) 111cm |
(M) 113cm (G) 113cm |
(M) 103cm (G) 111cm |
(M) 108cm (G) 113cm |
| BARREL LENGTH (M) MEDIUM CAL (G) MAGNUM CAL. | (M) 58cm (G) 61cm |
(M) 50cm (G) 58cm |
(M) 52cm (G) 58cm |
(M) 50cm (G) 58cm |
(M) 60cm (G) 60cm |
(M) 50cm (G) 58cm |
(M) 55cm (G) 60cm |
